The most compact housing in the industry

No other aluminum rolling shutter can match the extraordinarily compact housing sizes:

  • 72″ Unit height = 6.0″ housing.
  • 144″ Unit height = 7.0″ housing.

This Nautilus may be small in size, but it’s huge in strength!

Tested for large missile impact. Approved for FBC NHVHZ, FL 12246 and FBC HVHZ, FL17079.

Nautilus Span & Design Pressure Capacity:

  • 96″ Span = 160psf Concrete, 160psf Filled Block
  • 144″ Span = 106psf Concrete, 95psf Filled Block
  • 192″ Span = 77psf Concrete, 63psf Filled Block
  • 240″ Span = 55psf Concrete, 45psf Filled Block
